Arena Max
By Conterra
Arena maintenance has never been so easy. The Arena Max features a revolutionary Depth Control System that gives you power to control your arena depth over the entire surface. With the easy-to-use top-wind jack, adjust grooming depth in seconds — once established, the distance between tire and tooth never changes. A second side-wind jack controls the arena comb so you decide the finish. The front floater bar auto-adjusts with your tires and constantly floats and levels the surface. The result: consistent, level ground every use.
Choose your model
Built to order · 4–6 weeks · Freight calculated at checkout · Backed by Conterra's limited warranty
Why owners love it
Reliable. Functional. Enjoyable.
Three promises every Conterra Arena Max has to keep on day one — and a decade in.
Reliable
gets the job done, ride after ride, season after season.
Functional
easy to use; dual depth—control jacks set cut and comb in seconds.
Enjoyable
instant gratification every time you cross the arena.
The case for the Arena Max
Engineered efficiency and proven quality
The flagship of the Conterra family — engineered for 3-point hitch tractors and built for facilities that demand show-quality footing on every ride. Angled scarifier shanks bite even the hardest packed footing, while the front floater bar auto-adjusts with the tires for superior leveling.
- Revolutionary Depth Control System — same pre-set depth every pass, tire-to-tooth distance never changes
- Top-wind jack controls cutting depth (0″ to 5″) with an easy-to-read depth gauge
- Side-wind jack controls the arena comb — light or deep harrow finish
- Front floater bar auto-adjusts with the tires for superior floating and leveling
- Angled scarifier shanks continually pull the groomer into the ground in the hardest conditions
- Works in all arena conditions — from hard-packed loam to sand
- Replaceable bolt-on hardened-steel teeth and 3/8″ plate-steel arena comb
- Three widths (76″, 88″, 112″) — match your facility size and tractor
Engineered efficiency
Why consistent dragging matters
Stable footing contributes to the safety, performance, and longevity of your horse. A well-worn path or depression is bound to cause harm — building a dragging habit is healthy for your horses, your riders, and overall arena maintenance. Timing is everything: it is better to drag more than necessary than to neglect the task. Whether your footing is natural or synthetic, ruts form fast, and the deeper they get the harder they are to fix.
Stable footing
safer rides, longer—lasting surface
Healthy for your horses
no ruts, no hot spots, no compaction
Timing is everything
drag often, drag light, never let ruts set
Specifications
Built tough, built to last
Built by Conterra for efficient, effective arena maintenance with a 3-point hitch tractor and engineered for all arena conditions, from hard-packed loam to sand.
- Hitch
- 3-point hitch tractor required
- Cutting depth
- 0″ to 5″, monitored by an easy-to-read depth gauge
- Depth control
- top-wind jack — same pre-set depth every pass
- Comb control
- independent side-wind jack
- Front floater bar
- auto-adjusts with the tires for superior leveling
- Scarifier shanks
- laser-cut 3/4″ steel plate, angled to bite hard-packed ground
- Scarifier teeth
- hardened steel, bolt-on, easy to change
- Arena comb
- laser-cut hardened 3/8″ plate steel
- Frame
- heavy-duty tubular construction in 1/4″, 3/8″, and 1/2″ steel
- Tires
- two premium wide-flotation tires with easy-lube hubs
- Widths available
- 76″, 88″, and 112″
- Finish
- durable paint
Choose your width
Model reference
Three sizes scale from compact tractors up to the largest commercial facilities. All models share a 79″ length.
- CAM 76 — 64″ comb × 79″ long — 18–25 hp recommended — 9 scarifier teeth — 779 lb
- CAM 88 — 76″ comb × 79″ long — 25–35 hp recommended — 11 scarifier teeth — 930 lb
- CAM 112 — 112″ wide × 79″ long — 35 hp+ recommended — 13 scarifier teeth — 1,130 lb
Extend your groomer
Accessories
Build out your Arena Max with Conterra accessories sized to its chassis.
- Profiler Bar AM — re-profile compacted footing back to spec depth, sized for the Arena Max
Maintenance habit
How often should I drag my arena?
It depends on how many horses use the arena. With a single horse, dragging every 2–3 days will adequately redistribute and level the footing. The more horses you have, the more often you'll need to drag. The important thing is to keep the arena surface as level as possible.
Explore the family
Other Performance Drags & Groomers
If the Arena Max isn't quite right, the Conterra family scales down for smaller facilities and pull-vehicle setups.
Frequently asked questions
What kind of tractor do I need?
The Arena Max requires a tractor with a 3-point hitch. CAM 76 pairs with 18–25 hp, CAM 88 with 25–35 hp, and CAM 112 with 35 hp+.
How is the Arena Max different from the Arena Rake?
Both use angled scarifier shanks, but the Arena Max is built for 3-point hitch tractors and adds a front floater bar that auto-adjusts with the tires for superior leveling. It's the flagship choice for larger facilities that need a wider pass (up to 112″) and heavier frame construction.
How deep can it cut?
0″ to 5″, controlled by the top-wind jack and monitored with the easy-to-read depth gauge. Once set, the tire-to-tooth distance stays consistent every pass.
What widths and weights are available?
Three models — CAM 76 (64″ comb / 779 lb), CAM 88 (76″ comb / 930 lb), and CAM 112 (112″ wide / 1,130 lb). All are 79″ long with the same frame architecture.
Are the teeth and comb replaceable?
Yes. The hardened-steel scarifier teeth bolt on for easy changes, and the 3/8″ plate-steel arena comb is laser-cut and replaceable as a wear part.
What's the lead time?
Groomers are built to order. Expect 4–6 weeks for production and delivery. Shipping is calculated prior to delivery.
How often should I drag my arena?
With one horse, every 2–3 days is enough. With more horses or heavier use, drag more often. The goal is to keep the surface as level as possible — consistency matters more than aggression.
